In Stock
Part Number: 00579R UPC: 767676910674 Weight: 230

Description

Drive Motor

•  HD 115 V, universal AC/DC 50/60 Hz. Develops up to 2-3/4 HP

•  6 brush motor for higher torque



Pipe Cutter and Reamer

•  Precision pipe cutter with dual guide for accurate pipe cutting

•  5-blade conical reamer



No-Load Spindle Speed

•  72 rpm, Optional 54 and 100 rpm



HSS Precision Dies

•  Long operating life

•  Optimum cutting geometry and excellent chip discharge

•  Can be resharpened



Pipe Chuck

•  Collins SUPER GRIP chucking system offers R/L chucking. 4 heavy duty jaws at both front and rear of machine ensure that pipe is automatically gripped and centered.

•  Easy to replace for both metal and plastic-coated pipe

•  Need special jaws for plastic



Oiling and Lubrication

•  Rugged and proven oil pump

•  Automatic oil feed for optimum cooling

•  Large, easy-to-empty chip tray

•  1 gallon oil reservoir

•  Use ROCOOL cutting oil, a special blend of sulfo-chlorinated mineral oil assures long die life and superior quality threads



Die Heads

•  Snap-O-Matic die heads (2) are standard, fast operating

•  Simple, quick change of dies without time consuming adjustments

•  All controls are clearly marked

•  Automatically adjusted thread length

•  Adjustable thread depth

•  Long thread facility

•  Threading range: Pipe or conduit - 1/8" to 2"; Bolt or rod - 1/4" to 2-1/4"

•  Uniquad head optional



Safety

•  All units come with safety foot switch



Dimensions

•  37-1/2" x 13-1/8" x 18-1/2" (L x W x H)

•  Carriage travel 11"



Optional Stands (sold separately)

•  Open wheel stand with tool tray (00045)

•  Closed wheel stand with locking tool cabinet
