SKU: Fluke I800
UPC: 095969401227
Weight: 2.15
Fluke I800 AC Current Clamp Probe
Details
INCLUDES:
• (1) AC Current Clamp
FEATURES:
• Make contact thermometer measurements right away with the included Type-K thermocouple bead probe
• 1000:1 conversion factor for easy calculation
• Rugged positive action design
• Measures AC current from 100 mA to 800 A rms
SPECIFICATIONS:
• CAT III 600 V rating
• 30 Hz to 10 kHz frequency range
• Maximum conductor diameter: 54 mm (2.13 in)
• Output cable length: 1.6 m (63 in)
• Lead connector: Shrouded banana plugs
The Fluke i800 is a clamp-on AC current probe designed to extend the current measuring capability of a digital multimeter to 800 amperes AC. The clamp is compatible with a DMM that accepts 4mm shrouded banana plugs and has an AC milliamp range.
