Part Number: DWE7480 UPC: 885911322461 Weight: 57

Description





FEATURES:

• Rack and pinion telescoping fence rails make fence adjustments fast, smooth and accurate

• 24" of rip capacity, easily cuts a variety of larger shelving and trim materials

• Site-Pro Modular Guarding System allows for tool free adjustments of the guarding components appropriate for each application

• 15 Amp 4800 rpm motor quickly rips through hardwoods with ease

• On Board Storage provides easy access to the Site-Pro Guarding components and push stick when not in use

• Metal roll cage base offers greater durability than plastic bases

• Blade can be adjusted 0 - 45 degrees for bevel applications

• Weighing only 48 lbs, the DWE7480 can easily be moved on and off the job

• Adjustable rear feet designed to level the saw on uneven work surfaces

• Dust port allows for 2-1/2" vacuum hook up and minimizes clean up

• 24T carbide blade enhances cut quality and prolongs blade life

• Table coating reduces friction for smoother cutting



SPECIFICATIONS:

• Amps: 15.0Amps

• Horsepower: HP

• No Load Speed: 4800rpm

• Blade Diameter: 10"

• Arbor Size: 5/8"

• Dust Port Diameter: 2-1/2"

• Depth of Cut at 90°: 3-1/8"

• Depth of Cut at 45°: 2-1/4"

• Max Rip To Right Of Blade: 24""

• Max Rip To Left Of Blade: 12"

• Max Width of Dado: N/A"

• Tool Weight: 48lbs

• Shipping Weight: 57lbs
